Annex
|
Parameter |
Symbol |
Min |
Typ |
Max |
Unit |
||
|
Optical parameters |
|||||||
|
Operating wavelength |
l |
1530 |
1550 |
1565 |
nm |
||
|
Insertion loss |
IL |
|
3 |
3.5 |
dB |
||
|
Optical return loss |
ORL |
|
|
-45 |
dB |
||
|
Polarization extinction ratio |
PER |
20 |
|
|
dB |
||
|
Optical fiber |
Input port |
|
850nm PM fiber(125/250μm) |
||||
|
output port |
|
850nm PM fiber(125/250μm) |
|||||
|
Optical fiber interface |
|
FC/PC、FC/APC Or Customization |
|||||
|
Electrical parameters |
|||||||
|
Operating bandwidth （-3dB） |
S21 |
10 |
12 |
|
GHz |
||
|
Half-wave voltage @50KHz |
VΠ |
|
3 |
3.5 |
V |
||
|
Electrical return loss |
S11 |
|
-12 |
-10 |
dB |
||
|
Input impedance |
ZRF |
50 |
W |
||||
|
Electrical interface |
|
SMA(f) |
|||||
Limit Conditions
|
Parameter |
Symbol |
Unit |
Min |
Typ |
Max |
|
Input optical power |
Pin,Max |
dBm |
|
|
20 |
|
Input RF power |
|
dBm |
|
|
28 |
|
Operating temperature |
Top |
℃ |
-10 |
|
60 |
|
Storage temperature |
Tst |
℃ |
-40 |
|
85 |
|
Humidity |
RH |
% |
5 |
|
90 |
