Features
Operating wavelength 850~1650nm、320-1000nm
Fixed gain
High sensitivity
Low noise
Applications
Optical fiber sensing system
Low light detection system
Performance parameter
Type parameter
ROF-HSP-100-A
ROF-APR-100-B
Spectral response range
850~1650nm
320~1000nm
Material
InGaAs
Si
Light input
Photosensitive surface diameter
-
75um
-
1mm
-3dB bandwidth
DC-100Hz
DC-100Hz
Rise time
3ms
3ms
Responsiveness
0.9A/W@1550nm
0.5A/W@700nm
Gain
0.8×109V/W
0.4×109V/W
Minimum probe power
-83dBm
-80dBm
Saturated optical power
5nW
10nW
Operating voltage
DC ±5V
Operating circuit
80mA
Input interface
FC
Output interface
SMA
Output coupling
DC
Dimensions
60x50x20
Ordering information
|
ROF |
HSP |
100 |
X |
XX |
|
|
Photoreceiver
|
-3dBbandwidth -100Hz |
Operating wavelength A:850-1650nm B:320-1000nm |
Input type FC ---- optical fiber coupling FS ---- Free space |
*please contact our seller if you have special requirements
